Additional information
| Sensor | 1/2.8",2.0 megapixel, progressive scan, CMOS |
|---|---|
| Lens | 4.5 ~ 148.5mm, AF automatic focusing and motorized zoom lens |
| Angle of View (H) | 56.2° ~ 2.6° |
| Iris | Auto; F1.5 ~ F4.0 |
| Shutter | Auto/Manual,1 ~ 1/100000s |
| Minimum Illumination | Colour:0.001Lux (F1.5, AGC ON)0 Lux with IR |
| S/N | >52dB |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Max. Resolution | 1920*1080 |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Frame Rate | Main Stream: 2MP(1920*1080),Max60fps;Sub Stream: 2MP (1920*1080), Max60fps;Third Stream: D1 (720*576), Max 60fps; |
| Video Streaming | Triple |
| OSD | Up to 8 OSDs |
| Privacy Mask | 24 areas, upto 4 areas per scene |
| Digital Zoom | 16 |
| Audio Compression | G.711U,G.711A |
| Two-way audio | Supported |
| Edge Storage | Micro SD, up to 256 GB |
| Protocols | Pv4, IGMP, ICMP, ARP, TCP, UDP, DHCP,PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, HTTP, HTTPS, SMTP, 802.1x,SNMP, RTMP |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| Pan Speed | 0.1°/s ~200°/s Preset speed: 300°/s |
| Tilt Range | –15° ~90° (auto reverse) |
| Number of Preset | 1024 |
| Patrol | 16 patrols, up to 64 presets for each patrol,16 patrols, up to 32 actions for each patrol |
| Pattern | Up to 16 patterns, with the total recording time not less 15 mni utes per pattern |
| Audio I/O | 1/1 |
| Alarm I/O | 2/1 |
| Network | 1*RJ45 10M/100M Base-TX Ethernet |
| Power | AC 24V±25%, DC 24V±25%, PoE (PSE Required) Power consumption:MAX 41W) |
| Dimensions (Ø x H) | Ø227×384.8mm (Ø8.9” x 15.1”) |
| Weight | 5.39kg(11.88lb) |
| Working Environment | -40°C ~70°C (-40°F ~ 158°F) , Humidity: ≤95% RH (non-condensing) |
| Reset Button | Support |
