Additional information
| Frequency Range | Dual band: TX: 134 – 174MHz and 400 – 480MHz |
|---|---|
| Channel Capacity | 809 Channels |
| Channel Steps | 2.5 / 5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 50 KHz |
| Modes of Emission | F3 |
| Antenna Impedance | 50 Ohms, Unbalanced (Antenna Duplexer Built-in) |
| Frequency Stability | *5ppm@-140ºF ~ +140ºF (-10ºC ~ +60ºC) |
| Operating Temperature Range | 13.8VDC (*15%), Negative Ground |
| Supply Voltage | -4ºF ~ +140ºF (-20ºC ~ +60ºC) |
| Current Consumption (Approx.) | RX: 0.5 A (Squelched) |
| Case Size (W x H x D) | 140 x 41.5 x 168 mm (w/o knobs & connectors) |
| Weight | 1000g |
| Output Power | 50 / 20 / 10 / 5 W (144 MHz) |
| Modulation Type | Variable Reactance |
| Maximum Deviation | Better than -60dB (29 MHz: Better than -50dB) |
| Modulation Distortion | Less than 3% |
| Microphone Impedance | 2 kΩ |
| Circuit type | Double Conversion super-heterodyne |
| Intermediate Frequencies | 49.95 MHz / 450 KHz (Left band) |
| Sensitivity (for 12dB SINAD) | Better than 0.2 μ V |
| Squelch Sensitivity | Better than 0.16 μ V |
| Selectivity | 12 KHz / 30 KHz |
| Maximum AF Output | 2 W @ 8 Ω for 5% THD |
| AF Output Impedance | 4 – 6 Ω |
